Zoom LiveTrak L-20

144
iZotope RX 11 Elements for free!

iZotope RX 11 Elements for free!

If you purchase this product by 15-01-2025, you will receive a RX 11 Elements licence with a value of EUR 99,00 for free on top from iZotope!

Combined Mixer, Audio Interface and Recorder

  • 20 Discrete channels
  • 16 Mono plus 2 stereo channels with XLR and 1/4" phone jacks
  • Simultaneous recording of 22 tracks
  • Playback of 20 tracks
  • USB audio interface with 22 inputs and 4 outputs
  • Audio recording up to 24-bit / 96 kHz on SD storage media
  • 48 V phantom power
  • Hi-Z Connectors (channels 1-2)
  • 26 dB Pad (channels 3 to 16)
  • Compressor per channel with one knob (channels 1 to 16)
  • Solo and mute buttons for each channel
  • Low cut per channel between 40 - 600 Hz variably adjustable
  • Sum outputs and six configurable monitor outputs
  • Monitor outputs can be configured as headphone output or normal line-level output
  • Additional separate headphone output
  • Memory function for up to nine mixer scenes
  • 20 Internal, editable chorus, delay and reverb effects
  • Two effect buses
  • Built-in talkback microphone
  • Pre-record function
  • Class-compliant operation (for iOS compatibility)
  • Automatic start and stop recording possible
  • Import and export of projects via the USB 2.0 interface
  • Compatible functions for the ZOOM FS01 footswitch
  • Dimensions (W x D x H): 445 x 388.4 x 82.6 mm
  • Weight: 3.71 kg
  • Includes power supply (AD-19), USB 2.0 cable and quick start guide
  • Suitable protective cover: Article no. 514006 (not included)
  • Optional case 514831 (not included)
Available since September 2018
Item number 444179
Sales Unit 1 piece(s)
Recording / Playback Channels 22x4
Number of Mic Inputs 16
Number of Line Inputs 16
Instrument Inputs 2
Number of Line Outs 8
Headphone Outs 7
Phantom power Yes
Number of S/PDIF Connectors 0
Number of ADAT Connectors 0
Numer of AES/EBU Connectors 0
Number of MADI Connectors 0
Ethernet 0
Other Connectors No
MIDI interface No
Word Clock No
Max. sample rate (kHz) 96 kHz
Max. resolution in bit 24 bit
USB Bus-Powered No
Incl. power supply Yes
USB Version 2.0
Width in mm 445 mm
Depth in mm 388,4 mm
Height in mm 82,6 mm
Connection Format USB port Type B, Type A
User Interface Physical
Number Of Tracks 20
Number of faders 21
Simultaneous Recording: Amount Of Tracks 22
DSP Input channels 16
Effects 1
Storage Medium SD, USB
DSP Output Channels 8
Busses 8
Mic Preamp 16
XLR Connectors 16
Jack Connectors 16
Mono-Line Input 16
Stereo-Line Input 2
RCA Connectors 1
MIDI Interface None
Physical outputs 8
Digital stagebox connection No
USB connection 1
Digital Connections None
Miscellaneous Connectors Control In
Hotspot No
Headphone connection 1
Multitrack Record Yes
Soundcard interface USB-B
Options Audiointerface, Compressor
integratated Player/Rec via USB/SD Multitrack
Recorder Format WAV
RTA No
FX Processor 2
31 Band EQ 0
Matrix 0
DCA/VCA Groups 0
Midi Connector No
Sample rate 44,1/48/96 kHz
Separate Personal Monitor system No
Expansion Card slots 0
Digital ADAT No
Included in delivery Power Supply (AD-19), USB 2.0 Cable, Manual
Digital SPDIF No
Digital AES3/ASESEB No
Digital MADI No
Zero latency monitoring 1
Digital Dante No
110V capable 1
Case Optional
19" Rackmount Optional
Height 83 mm
Width 445 mm
Depth 39 mm
Weight 3,71 kg
Show more
£759
All prices incl. VAT
In stock
In stock

This product is in stock and can be shipped immediately.

Standard Delivery Times
Delivery free of charge expected between Thursday, 12.12. and Friday, 13.12.
1

144 Customer ratings

4.7 / 5

You have to be logged in to rate products.

Note: To prevent ratings from being based on hearsay, smattering or surreptitious advertising we only allow ratings from real users on our website, who have bought the equipment from us.

After logging in you will also find all items you can rate under rate products in the customer centre.

handling

features

sound

quality

98 Reviews

b
A dream machine for a medium sized band.
billfromcork 14.04.2021
I bought this to use in a rehearsal room with a band. We are a four piece but use drums, 2 guitars, bass, 3 synths (stereo),laptop and 3 vocals so needed lots of inputs.
Previously had a Yamaha mixer and Zoom R16 recorder but this allows us to play live and/or record without continuously plugging in and out inputs into the mixer and recorder. Recording onto SD card is easy.
Sound quality is great, loads of headroom on preamps, channel tweaking is easy. Greatest of all though is the ability to have 6 individual headphone/monitor mixes.

Haven't tried mixing using it hooked up to my DAW yet - will report back.

Con: Sure, it's a bit plasticy and the knobs aren't pro quality but sitting in a bandroom with the occasional trip into the outside world it is easily robust enough to last a long time.

1 Year update: I can confirm this product is great. We've used it to produce high quality band demos. Instead of recording all the tracks onto SD card and then importing into a DAW (which is very easily done) we now have it connected directly to a laptop and record live into the DAW. We have a template for our band and all the inputs set up in the DAW so it's really quick and easy to record rehearsals or demos.

Highly recommended, great value.
handling
features
sound
quality
17
3
Report

Report

Z
Plug & play
Zjado 20.08.2021
Easy to install, good quality
handling
features
sound
quality
1
1
Report

Report

M
Very good value for its price
Max22666 14.10.2022
It does what it says it does !
Pretty simple to use and gives very good results.
Only "-" are :
- Not enough buttons for the recorder side so you have to use the small screen which is not very handful
- You have to reboot every time you want to change mode
handling
features
sound
quality
1
0
Report

Report

S
Very good
Stofzuigzakkie 27.10.2021
our band is very very happy with this mixer! I love the preset option, the monitor option, the recording option (with an option to listen back and select the channels you want to listen to).
Amazing for the price and great if you play in a band and want to record your songs easily
handling
features
sound
quality
1
0
Report

Report
